28A double-knife ring type self-locking with lamp

Short Description:

·Product Model:  Q28A

·Type:Double pole,Self-locking

·Material:304 stainless steel housing，PA66

·Protection level: IP65, IK10, IP40.

·Electrical parameters: 5A /250VAC

·Insulation resistance:≥ 1000MΩ

·LED voltage: 3V-220V

·Service temperature range: -20℃—55℃

·Lamp bead life:40,000 hours

·Mechanical life:30 times/min，500,000 times

·Contact resistance:≤50Ω

:
